Helios Flush mounted Room fan HV 250/4 R HELIOVENT
€345.25
Bezahlen Sie sicher und schnell mit:
Flush mounted Room fan for installation in Walls, Shafts and thin Panels. Usable for the supply and extract ventilation medium to large Rooms.
Plastic housing with elegant, room-side Fascia in alpine white. Fascia for the Cover the Intake opening with after top directed Blades. For the Cleaning in the Water bathroom removable.
High-pressure High power impeller made of Plastic with 7 Blades, for high Pressure- and Volume power.
Einphasen Alternating current Capacitor Motor, closed Design, maintenance-free, with in the Winding installed Thermal contact, speed-controllable through Voltage reducer, sealed, low-noise Ball bearings with Lifetime lubrication, reversible.
Dokumente
| Degree of protection: | IP 54 |
|---|---|
| Nominal pipe diameter: | 250 mm |
| Height: | 337 mm |
| Width: | 337 mm |
| Material: | Housing made of Plastic; Impeller made of Plastic |
| Airflow rate: | 840 m³/h |
| Color: | Alpine white |
| Controllability: | Transformer / Electrically |
| Current uncontrolled: | 0.2 A |
| Depth: | 39 mm |
| Installation: | Walls, Shafts and thin Panels |
| Number of poles: | 4 |
| Permissible medium temperature: | 40 °C |
| Rated power: | 0.04 kW |
| Rated speed: | 1380 |
