Maico Central Ventilation unit WS 170 KLET

Comfort version

• Comfort version with Preheating coil, sound optimized Housing with Additional insulation and Enthalpy heat exchanger.

• Unit as Left-hand version.

• ISO Coarse 80 % (G4) Filter in the Extract air and ISO ePM1 55 % (F7) Pollen filter in the Outside air.

Short description

• Central compact very quiet Residential ventilation unit with heat recovery.

• for controlled supply and extract ventilation.

• Highly efficient Ventilation unit achieves Energy efficiency class A.

• Particularly suitable for modern New construction and Renovations (z.B. Apartments).

• The narrow Ventilation unit (Width: 59,5 cm) is also particularly ideal for the Kitchen installation.

• KfW funding eligibility and NRW funding are provided.

• Easy, very time-saving Installation with the included in the scope of delivery contain Wall mount.

• A Filter cascade (ISO Coarse 80 % (G4) / ISO ePM1 55 % (F7)) in the Outside air is possible for the Increase in filter service life.

• All Units are equipped with state-of-the-art Cross-counterflow heat exchanger, or. Enthalpy heat exchanger with Hygiene certificate after VDI 6022, Blade 1.

• complete separation the Extract air-/ Supply air routing throughout the entire Unit. Thereby is unwanted Recirculation mode prevents. Viruses (z.B. Coronavirus) and Bacteria are thus not transmitted.

• Room air control RLS 1 WR included in the scope of delivery.

• All Residential ventilation units are via app (air@home) and the browser-based Webtool (www.air-home.de) using integrated LAN interface controllable.

• As standard USB connection for the Commissioning, Control software update and Service.

• All Units are equipped with highly energy-efficient Fans in EC technology.

• The integrated /automatic Constant airflow control ensures for a durable Compliance of the set Airflow rate under all Operating conditions (z.B. Filter contamination, Air valve settings). Thus results in itself also a easier Commissioning / Airflow balancing at the Valves.

• As standard integrated Combined sensor (Humidity / Temperature) in the Extract air enables a demand-controlled Ventilation operation as well as a intelligent Frost protection- and Dehumidification strategy (Excess humidity protection).

• All Units are characterized itself made of through a at the actual Demand adapted Frost protection strategy.

• 2 Input contacts (12 V and 230 V) are available for z.B. safety-related Shutdowns.

• Various inputs/outputs enable a control-related Connection to other building-services Unit z.B. Heat pump.

• Integrated Modbus interface (TCP/IP and RTU) for Integration in the Building management system.

• The optional Plug-in module K-SM enables the Integration in the KNX building systems.

• The optional Plug-in module E-SM enables the Integration in EnOcean systems.

• Optional Additional circuit boards ZP 1 and ZP 2 for Extension functions such as z.B. „Constant pressure control“ the EC fans, Zone damper, Brine ground heat exchanger (controlled Pump), Filter differential pressure measurement.

• Maximum unit flexibility through various Equipment-/ Connection options.

• Modern modular unit technology enables a easy Retrofittability (z.B. Preheating, Bypass) as well as high User-friendliness for Service and Maintenance.
