Maico Small-room fan ECA 100 ipro RC
High-performance Maico Fan for Industry and Commercial applications
Regular price:
€349.86
Product number:
10817731
Stock:
0
Manufacturer:
Maico
Manufacturer number:
0084.0210
Kostenloser Versand für dieses Produkt
Sicher kaufen mit Trusted Shops
Immer 100 Tage Widerrufsrecht
Bezahlen Sie sicher und schnell mit:
Sofort
VISA
PayPal
RIVERTY
Description
Version with Radio receiver:
- With integrated Radio receiver 868 MHz.
- A/On/off via Wireless switch DS RC or separate Control RLS RC.
- The two Speed can either at the Wireless switch or at the Control selected are.
- Not speed-controllable.
Features:
- Radio-controlled Fan for the Extract air system MAICOsmart, with installed Radio receiver 868 MHz, on EnOcean Technology based.
- The Fan can in a Master – Slave Assembly installed are (RLS RC required).
- Two Performance level.
- Conceals Intake through Design cover.
- For the Exhaust ventilation.
- With VDE Mark.
- Degree of protection IP X5 for Safety in the Bathroom.
- Protection class II.
- Colour traffic white similar RAL 9016.
- Housing made of impact-resistant Plastic.
- Combinable with Wibutler Smart-Home-System.
Motor:
- Energy-saving, robust Motor with Ball bearings, maintenance-free.
- For Continuous operation suitable.
Installation instructions:
- Easy Installation, because Cover easy with Tool removable.
- Compatible to ECA Predecessor models DN 100, because Mounting holes and Cable entry Flush-mounted at the same Position.
Electrical Connection:
- Electrical Connection Flush-mounted.
Safety notice:
- The Fans comply the Degree of protection IP X5 and can thus in the Protection range 1 according to DIN VDE 0100-701 installed are.
- Details see Planning instructions Chapter Small-room fan.
Dokumente
Properties
| Degree of protection: | IP X5 |
|---|---|
| Nominal pipe diameter: | 100 mm |
| Height: | 159 mm |
| Width: | 159 mm |
| Material: | Plastic |
| Airflow rate: | 78/92 m³/h |
| Color: | traffic white, similar RAL 9016 |
| Air direction: | Extract air |
| Depth: | 130 mm |
| Installation: | Installation location: Ceiling / Wall installation type: Surface-mounted installation position: any |
| Max ambient temperature: | -10 °C to 40 °C |
| Permissible medium temperature: | 40 °C |
| Rated frequency: | 50 Hz |
| Rated power: | 0,006/0,008 kW |
| Rated speed: | 2,100 / 2,500 |
| Sound pressure level: | 27 dB(A) / 32 dB(A) / distance 3 m, free-field conditions |
