Maico Small-room fan ECA 150 ipro VZC

Version with adjustable Switch-on delay and Run-on time:

• A/On/off via Light switch or separate Switch.

• All 4 Operating programs selectable.

• Sequence the Performance level takes place per after selected Operating program.

• Switch-on delay multi-stage via easy accessible Push button adjustable: 0/50/90/120 sek.

• Run-on time multi-stage via easy accessible Push button adjustable: 0/8/17/25 min.

• Set Time is using LED's during the Setting displayed.

• Not speed-controllable.

Operating programs:

• Adjustable via Jumper in the Unit.

• Comfort program (before set)
  User present: Stage 1
  Run-on time: Stage 2

• Demand program
  User present: Stage 2
  Run-on time: Stage 1

• Economy program
  User present: Stage 1
  Run-on time: Stage 1

• Power program
  User present: Stage 2
  Run-on time: Stage 2

Features:

• Intelligent programmed Small-room fan for highest Requirements.

• 2 Performance level.

• Conceals Intake through Design cover.

• For the Exhaust ventilation.

• Combined large Air volume with high Pressure rating.

• With VDE-GS Mark.

• Degree of protection IP X5 for Safety in the Bathroom.

• Protection class II.

• Thermal Overload protection.

• For Continuous operation suitable.

• Colour traffic white similar RAL 9016.

• Housing made of impact-resistant Plastic.

Motor:

• Energy-saving, robust Motor with Ball bearings maintenance-free.

• For Continuous operation suitable.

Installation instructions:

• Compatible to ECA Predecessor models DN 150, because Mounting holes and Cable entry Flush-mounted at the same Position.

• Wall- and Ceiling mounting possible.

Electrical Connection:

• Electrical Connection optionally On- or Flush-mounted.

Safety instructions:

• All ECA 150 ipro Units in the Protection range 1 according to DIN VDE 0100-701 usable.

• Details see Planning instructions.
