Ruck Inline fan ISOR 125 EC K 01
€512.83
Bezahlen Sie sicher und schnell mit:
Fully insulated Fan box for installation in Ventilation ducts. For the easy Installation in Ducts are the Connection spigot with a Lip seal provided. Housing made of galvanized sheet steel with sound-absorbing Internal lining made of 40 mm Mineral wool with abrasion-resistant Glass-silk facing according to DIN EN 13 501-1, Class A1. Installation position horizontal and vertical possible. Through a removable Cover is the swing-out Fan unit easy to clean. Fan unit made of Sound-insulated housing easy removable. With integrated Mounting tab for easy Installation.
A efficiency optimized backward curved Impeller is on the Rotor of the voltage control External rotor motor constructed. The Impeller is according to the Quality grade G 6.3 after DIN/ISO 1940 on 2 Levels made of balanced. Drive motor closed, maintenance-free Ball bearings with Lifetime lubrication, on both sides closed. All Fans as standard with Motor protection through Thermal contact and internal verschaltetem Motor capacitor. The electrical Connection takes place via a external Terminal box.
CE Marking according to EG Declaration of conformity for Electromagnetic Compatibility EMV – Directive 2004/108/EG. EG – Declaration of incorporation after Machinery Directive 2006/42/EG – Directive 2009/125/EG (VO 1253/2014/EU).
| Nominal pipe diameter: | 125 mm |
|---|---|
| Height: | 232 mm |
| Width: | 383 mm |
| Material: | Brass CW617N |
| Depth: | 378 mm |
